SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 394 of 549
Pin
No.
Pin Name Description
1 CAN_H CAN High
2 CAN_L CAN Low
7 A_GND Common Switch GND
12 V bat Supply Voltage Battery
23 GND Power GND
9 Driver SIS+ Peripheral Acceleration Sensor Rear
Driver, Plus
10 Driver SIS- Peripheral Acceleration Sensor Rear
Driver, Minus
Please refer Airbag ECU Pin Assignment on or more details.
Inspection Method:- N.A.
CHAMBER B
CHAMBER A
