SRS / Airbag

ECU – DTC Troubleshooting Guide

Version: 14.0

Date: 14-February-2017

Prepared by:Airbag COC Review &

Approved by:Sanjeev VM

Page: 278 of 549

Pin

No.

Pin Name

Description

CAN_H

CAN High

CAN_L

CAN Low

A_GND

Common Switch GND

12 V bat

Supply Voltage Battery

23 GND

Power GND

Pin No.

Pin Name

Description

passenger

Side Airbag

Side Airbag Front Passenger,

Minus

passenger

Side Airbag

Side Airbag Front Passenger,

Plus

Please refer Airbag ECU Pin Assignment on

or more details.

Inspection Method:-

N.A.

CHAMBER B

CHAMBER A
