SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 275 of 549
REPLACE THE LSAB
MODULE
RECONNECT THE
AIRBAG
ECU,LSAB&AIRBAG
W/H IN THE
VEHICLE
CHECKWHETHER THE RESISTANCE ATOUTPUT PINS C208-2 &
C208-1 IN VEHICLEW/HW.R.T. GROUND IS BELOW 1 kΩ
