Trouble Shooting:-
Is DTC
B1F39 -23 is
Present?
Check for Fresh Air / Recirc
Request Button functionality.
Check the Fresh Air / Recirc
shall be change by pressing
Fresh Air / Recirc button
Is Fresh Air / Recirc
button stucked?
Check and lubricate switch if still the Fresh
Air / Recirc button is stucked then replace
control panel.
Clear the DTC from the ECU memory.
Turn Ignition OFF & ON.
Check the Fresh Air / Recirc shall be
change by pressing Fresh Air / Recirc
button
Stop
Stop
YES
NO
YES
NO
Turn ON Ignition.
Connect the TML Diagnostic Tool.
Check the status of DTC’s (Memorized/Current)
Record the DTC & Clear DTC’s
Turn Ignition OFF & ON
Verify If DTC B1F39 – 23 is present
