Pin Details:-
Pin
num
ber
Signal
Name
Signal
Descri
ption
A
SolarSensSig
Solar Sens(Sensor) Signal
B
SolarSensGnd
Solar Sens(Sensor) Gnd
Inspection Method: -
1) If there is no continuity between the sensor connector & ECU connector then correct the wiring harness
2) If there is a continuity between the sensor signal and battery lines correct the wiring harness (wiring harness short to
battery)
