DTC Troubleshooting Data
Version: 2.0
Date: 28-Jul-17
Author: ERC
Page: 165 of 244
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
a) Physical check of temperature change when requested.
b) Read ECU parameters
sensor Solar Load Status
Circuit Schematic Diagram:-
“Refer the circuit schematics from the tool”
Component Location & Image:-
Near Wind shield and on top of dash board.
Connector View & Information: -
