DTC Troubleshooting Data
Version: 2.0
Date: 28-Jul-17
Author: ERC
Page: 129 of 244
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
START
CONNECT THE DIAGNOSTIC TOOL
AND CHECK FOR DTC’S
IS DTC
PRESENT?
CHECK DTC PRESENT IS PERMANENT OR
HISTORY
IS DTC
PERMANENT?
CLEAR DTC
CHECK THE FATC HVAC SIDE CONNECTOR
(BLUE) &MODE ACTUATOR FOR PIN BACK OUT
ARE PINS
OK?
IS CONTINUITY
PRESENT?
MODE MOTOR DRIVE LINE IS SHORT
TO GROUND
IF ALL THE
ABOVE CHECKS
FAIL
STOP
FIX THE
PROBLEM
IS DTC
PRESENT?
NO
YES
CHECK FOR THE CONTINUITY BETWEEN PIN NO 15,PIN
NO 14 OF FATC HVAC SIDE ECU CONNECTOR(BLUE)
AND GROUND PIN N0 1,2 OF VEHICLE SIDE ( GREEN)
CONNECTOR
HIGH RISK OF
ECU DAMAGE
RECTIFY THE
WIRING
HARNESS
REPLACE ECU
B1F2E-
11::MODE (AIR
DISTRIB) DRIVE
LINE SHORT TO
GROUND
YES
YES
NO
NO
YES
NO
CRANK THE
VEHICLE AND
CHECK FOR
DTC’S
NO
ECU IS FAULTY
YES
