X2 Eagle
ABS DTC Troubleshooting Data
Version: 1.0
Date: 03-Dec-15
Author: ERC, Chassis E&E CoC
Page: 142 of 154
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:
START
1. Turn OFF ignition
2. Wait for 5 seconds
3. Turn ON ignition
4. Connect the diagnostics tool and Read Logged DTCs
Is U0101–08
logged in
current state?
Do necessary repairs in the wiring harness.
1. Check if Ignition (Pin 9), Battery (Pin 4) and
Ground (Pin 5) of TCM ECU is properly connected
2. Check for any blown/disconnected fuse at
Ignition and Battery lines of TCM connector
Is continuity
there?
1. Check for continuity between
TCM CAN_H (Pin 10) to IPC CAN_H (Pin 5) & TCM
CAN_L (Pin 11) to IPC CAN_L (Pin 4) in vehicle
wiring side connector
Do necessary repairs in the wiring harness.
Clear DTC
STOP
Y
Y
N (In History)
N
