X2 Eagle
ABS DTC Troubleshooting Data
Version: 1.0
Date: 03-Dec-15
Author: ERC, Chassis E&E CoC
Page: 4 of 154
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
TABLE OF CONTENTS
C0031-14:- Left Front Wheel Speed Sensor- Circuit short to Ground or open ........................................................6 C0031-12 :- Left Front Wheel Speed Sensor- Circuit Short to Battery .....................................................................9 C0031-64 :- Left Front Wheel Speed Sensor- Signal Plausibility Failure.................................................................12 C0031-62 :- Left Front Wheel Speed Sensor- Signal Compare Failure ...................................................................16 C0034-14:- Right Front Wheel Speed Sensor- Circuit short to Ground or open ....................................................20 C0034-12:- Right Front Wheel Speed Sensor- Circuit Short to Battery ..................................................................23 C0034-64:- Right Front Wheel Speed Sensor- Signal Plausibility Failure ...............................................................26 C0034-62:- Right Front Wheel Speed Sensor- Signal Compare Failure ..................................................................29 C0037-14:- Left Rear Wheel Speed Sensor- Circuit short to Ground or open........................................................33 C0037-12:- Left Rear Wheel Speed Sensor- Circuit Short to Battery .....................................................................36 C0037-64:- Left Rear Wheel Speed Sensor- Signal Plausibility Failure...................................................................39 C0037-62:- Left Rear Wheel Speed Sensor- Signal Compare Failure .....................................................................42 C003A-14:- Right Rear Wheel Speed Sensor- Circuit short to Ground or open .....................................................46 C003A-12:- Right Rear Wheel Speed Sensor- Circuit Short to Battery ...................................................................49 C003A-64:- Right Rear Wheel Speed Sensor- Signal Plausibility Failure ................................................................52 C003A-62:- Right Rear Wheel Speed Sensor- Signal Compare Failure ...................................................................55 C131E-01:- Wheel Speed Sensor- General Electrical Failure..................................................................................59 C131E-12 :- Wheel speed sensor- Circuit short to battery ....................................................................................63 C0010-04:- Left Front Inlet Control-System internal Failure ..................................................................................66 C0014-04:- Right Front Inlet Control-System internal Failure................................................................................68 C001C- 04:- Right Rear Inlet Control-System internal Failure ................................................................................70 C0018-04:- Left Rear Inlet Control-System internal Failure ...................................................................................72 C0011-04:- Left Front Outlet Control-System internal Failure ...............................................................................74 C0015-04:- Right Front Outlet Control-System internal Failure .............................................................................76 C001D-04:- Right Rear Outlet Control-System internal Failure..............................................................................78 C0019-04:- Left Rear Outlet Control-System internal Failure ................................................................................80 C1025-09:- Generic Valve-Component failure........................................................................................................82 C1026-1C:- Valve supply- Circuit Voltage out of Range..........................................................................................84 C100C-96:- Pump Motor- Component Internal Failure..........................................................................................87 C100C-01:- Pump Motor- General Electrical Failure ..............................................................................................89 C100D-4B:- Pump Motor Flow rate- Over Temperature ........................................................................................93
