55
B1320 - 12
Drive signal for Back Antenna - circuit short to battery
256
N
56
B1320 - 11
Drive signal for Back Antenna - circuit short to ground
261
N
57
B1321 - 13
Drive signal for Front Centre console Antenna - circuit
open
266
N
58
B1321 - 12
Drive signal for Front Centre console Antenna - circuit
short to battery
271
N
59
B1321 - 11
Drive signal for Front Centre console Antenna - circuit
short to ground
276
N
60
B131F - 13
Drive signal for Right Antenna - circuit open
281
N
61
B131F - 12
Drive signal for Right Antenna - circuit short to battery
286
N
62
B131F - 11
Drive signal for Right Antenna - circuit short to ground
291
N
63
B1032 - 62
ESCL Lock and Unlock States - signal compare failure
296
N
64
B164D - 00
No communication to EMS - no sub type information
300
N
65
B164C - 00
No communication to ESCL - no sub type information
304
N
66
B131B - 11
Rear Right Door Handle Switch - circuit short to ground
308
Y
67
B131B - 15
Rear Right Door Handle Switch - circuit short to battery or
open
309
Y
68
B131C - 11
Rear Left Door Handle Switch - circuit short to ground
310
Y
69
B131C - 15
Rear Left Door Handle Switch - circuit short to battery or
open
311
Y
70
B131E - 11
Drive signal for Left Antenna - circuit short to ground
312
Y
71
B131E - 12
Drive signal for Left Antenna - circuit short to battery
313
Y
72
B131E - 13
Drive signal for Left Antenna - circuit open
314
Y
73
U0028 - 13
Vehicle Communication Bus A – Open Circuit
315
Y
74
U0028 - 88
Vehicle Communication Bus B – Bus off
317
Y
75
U0100 - 08
Lost Communication with ECM – Message Time out
Failure
319
Y
76
U1309 - 08
Lost Communication with Anti – Lock Braking System –
ABS/ESP Message Time out Failure
324
Y
77
U131A – 08
Lost Communication with ESCL – Message Time out
Failure
330
Y
78
U0140- 08
Lost Communication with BCM – BCM Message Time out
Failure
334
Y
79
U0401 – 81
Invalid Data Received From ECM
339
Y
80
U1609 - 81
Invalid Data Received From ABS
342
Y
81
U0422 - 81
Invalid Data Received From BCM
345
Y
82
U0401 – 82
Invalid Data Received From ECM – Message Rolling
Counter Error
348
Y
83
U1609 – 82
Invalid Data Received From ABS/ESP – Message Rolling
Counter Error
351
Y
84
U0422 – 82
Invalid Data Received From BCM – Message Rolling
Counter Error
354
Y
85
U0401 – 83
Invalid Data Received From ECM – Cyclic Redundancy
Check Error
357
Y
