3601 / 4910
Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 319 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
U0100-08
:-
Lost communication with ECM- Message Timeout Failure
Overview:-
ISO Code
U0100-08
Customer Symptom
Cranking will not happen
Fault Effects (On Vehicle)
Cranking will not happen
Lamp Status (If Any)
N.A
Fault Detection Condition
1. ECM connector is not connected properly or disconnected
from its location
2. CAN Stub wire from ECM connector side is disconnected.
3. ECM ECU is not powered up.
Normal Operating Condition
ECM ECU communicates properly TML diagnostic Tool.
Probable Trouble Area
Disconnection of the ECM connector
Healing Condition
To fix the ECM connector correctly and Fix the wiring harness
issues from ECM side.
Table 68:- U0100 -08 overview details
