ECU Pin assignment (Applicable for petrol ECM)
Vehicle Connector-1
Pin No.
Pin Name
Description
132
CAN_H
CAN High
144
CAN_L
CAN Low
116
Ign
Ignition
155,156
Vbat
Supply Voltage Battery
153,154
GND
Battery GND
ECU Pin assignment (Applicable for Diesel ECM)
ECM Pin Details:-
Pin No.
Pin Name
Description
19
CAN_H
CAN High
18
CAN_L
CAN Low
49
Ign
Ignition
12.31
Vbat
Supply Voltage Battery
9, 28
GND
Battery GND
Inspection Method:- N.A
