Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 199 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Connector View & Information:-
PEPS
NOTE:-
Please refer PEPS ECU drawing for connector PIN details.
Inspection Method:-
1. In Ignition, if brake pedal is de-pressed/release telltale will turn-on & if brake pedal is pressed than brake telltale
on IPC will turn-off.
2. Press brake pedal followed by pressing Engine start/stop button, vehicle should crank.
