Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 193 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
Start
1. Keep vehicle in static condition.
2. Turn IGN ON.
3. Keep UID outside the vehicle.
4. Release clutch pedal.
5. Run input switch test routine.
6. Give clutch pedal transition. i.e
press and release.
7. Wait for routine to complete.
Is
DTC-1642-14
Present
?
Check & Fix for the cut & short to Ground on
the harness between wire of connector-2 /
pin-2 and brake signal.
Stop
No
Yes
DTC’s confirmation:-
1. If short to ground fault was created on the driver door handle switch and input switch test routine was executed.
Circuit Schematic Diagram:-
N.A
