EMS ECU:-
For EMS location please refer EMS ECU troubleshooting guide.
Connector Location:-
PEPS ECU:-
EMS ECU:-
For EMS connector location please refer EMS ECU troubleshooting guide.
Connector View & Information:-
NA
Inspection Method:-
1.
Check passive start is working fine.
2.
Check after IGN ON Immo telltale on instrument cluster shall stays OFF.
