153,154
GND
Battery GND
ECU Pin assignment (Applicable for Diesel ECM)
ECM Pin Details:
Pin No.
Pin Name
Description
19
CAN_H
CAN High
18
CAN_L
CAN Low
49
Ign
Ignition
12.31
Vbat
Supply Voltage Battery
9, 28
GND
Battery GND
Inspection Method:
NA
