U0028-88:- Vehicle Communication Bus A-Bus off
Overview:
ISO Code
U0028-88
Customer Symptom
EPAS lamp ON , CE Lamp ON,MIL Lamp ON,ABS Lamp
ON,TCM Lamp ON,SRS Lamp ON,EBD Lamp ON
Fault Effects (On Vehicle)
Vehicle cranking will not happen.
Lamp Status (If Any)
Vehicle cranking will not happen.
Fault Detection Condition
Short circuit between CAN_H -CAN_L, CAN_H -GND,
CAN_L-Vbatt lines. This DTC may also get logged in case of
CANH OR CAN L open circuit.
Normal Operating Condition
ECU communicates properly with all ECUs.
Probable Trouble Area
CAN_H and CAN_L wires
Healing Condition
Removal of the above mentioned shorts/open in the wiring
harness or at ECU pin.
Table 2: U0028-88 overview details
Troubleshooting:
U0028-88:- Vehicle Communication Bus A - short circuit
Start
Read DTC with diagnostic
tool..
This DTC will be in history.
Clear DTC
End
