Check countinuty between BCM connector pin

[C1-

42]

and BCM Battery voltage pin

[C3-1/ C3-2]

Continuity found?

Correct BCM side wiring harness

(Short To Battery)

Yes

1.Remove Door UnLock control others Relay mating

connector

2.Perform the visual check of connectors for pin bend or

damaged etc.

Is connector faulty?

Correct connector fault

(Terminals Bend)

1.Remove all BCM connector

2.Take out Door UnLock control others Relay output wire

[C1-42]

from connector

3.Reconnect all connectors including battery

4.Check if All doors are unlock?

All doors are u?

Reconnect all

connectors firmly

BCM ECU faulty

Replace BCM ECU

Yes
