Trouble Shooting:
Start
Turn IGN OFF – ON and wait for 5 seconds
Clear DTCs from BCM ECU
Turn IGN OFF – ON and Start the
Engine.
Wait for 5 seconds.
Provide Lock and Unlock command
Read DTCs from BCM ECU
Is B1630 - 62 DTC
present
Yes
Connect the vehicle battery, BCM, and
components, if disconnected. Measure Battery
Voltage
Is battery voltage in
range (9V to 16V)
Yes
Stop
No
Charge the battery and/or replace battery
No
B
A
B1630 - 62: Driver Door Lock/Unlock Signal - Signal
Compare Failure
