Step Checks
IF YES
IF NO
1.
Check whether the Rotary Drive Mode switch contacts are
stuck in closed condition.
Rectify/Replace the
Switch.
Go to Step 2.
2.
When the sport switch is struck for a time greater than
debounce time.
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic.
Go to Step 3.
3.
Check whether the Drive Mode rotary switch is physically
Damaged.
Rectify/Replace the
Switch.
Go to step 4.
4.
Check whether the EMS ecu pin K051 is short circuit to
Ground/ batt.
Establish continuity
as per the circuit
schematic.
Go to step 5.
5.
If fault still persists.
Replace economy
mode switch. IF fault
still persists then
Call hot line
Confirm the above
procedure for fault
Rectification..
DTC’s confirmation
(checks before handing over vehicle to customer)
:
1. Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also.
2. If error present, then rectify the errors.
3. Confirm that there is no error logged in EMS before handing over vehicle to customer.
