BCM ECU Faulty
Replace BCM ECU
Is connector
faulty?
Correct connector fault
(Terminals Bend)
YES
Continuity found?
Replace Combination switch (
Wiper )
YES
NO
Check countinuty between BCM connector pin
[C1-25] and [C4-7] OR [C1-25] and [C4-19] OR
[C4-19] and [C4-7]
NO
A
B
B225D–09:Combination Switch Failure (Wipers) – Component
Failures
DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
Check DTC B225D – 09 is not logged
