B225D – 09: Combination Switch Failures (Wipers) – Component Failures
Overview:
ISO Code
B225D – 09
Customer Symptom
Some or all combination switch (Wipers) operations may fail
Fault Effects (On Vehicle)
Some or all combination switch (Wipers) operations may fail.
Lamp Status (If Any)
-
Fault Detection Condition
BCM log this fault when combination switch (Wipers) fails. (
May be stuck / short to ground / short to Battery)
Normal Operating Condition
Probable Trouble Area
1. BCM connector Fault
2. Switch damaged
3. BCM ECU faulty
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Combination Switch (Wipers) is located near steering at the dashboard of the vehicle.
Preliminary Checks:
1. Check Battery Voltage (12.5 V & above)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
