B2229 – 15: Left Turn Indicator – Short to Battery or Open Circuit
Overview:
ISO Code
B2229 – 15
Customer Symptom
Left Turn Indicator Lamps always ON.
Fault Effects (On Vehicle)
1. Left Lamp always ON.
2. Battery Drain.
Lamp Status (If Any)
Always ON
Fault Detection Condition
This fault gets logged by BCM when left Turn Indicator lamp
output is shorted to battery or open circuit
Normal Operating Condition
Turn Indicator lamp comes ON when turn indicator switch is
activated.
Probable Trouble Area
1. BCM connector Fault
2. Left Turn Indicator lamp output wire Short to battery
or open circuit
3. Left Turn Indicator Lamp bulb blown /lamp damaged
4. BCM ECU fault
5. Left Turn Indicator lamp mating connector fault
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Left Turn Indicator lamps are located at left front, left rear and left side of the vehicle. Turn Indicator lamp comes
ON when turn indicator switch is activated.
Preliminary Checks:
1. Check Battery Voltage (12.5 V & above)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
