P0567-24: Cruise Control "Resume" Signal: Cruise plus button stuck key error

Overview:

DTC Description (User Friendly)

Cruise Control "Resume" Signal: Cruise plus button stuck key

error

ECU Pin Number

K029 – Input analog signal to EMS

K033 – Ground signal to cruise button from EMS ECU

Customer Symptom

MIL OFF, CEL OFF

Fault Effects (On Vehicle)

Lamp Status (If Any)

Fault Detection Condition (Root cause)

Cruise plus button stuck key error is detected if CrC_stKey

continuously remains in a state of CRC_STPLUS for a

duration of 60000 ms or 50 ms.

Normal Operating Condition

Proper wire harness connection between Cruise Cncl button

and EMS ECU.

Probable Trouble Area

Wire harness connection between Cruise Cncl button and

EMS ECU.

Healing Condition

Rectify the error Clear through diagnostic tool.

Ignition OFF & ON

Component Details:

Cruise control is a system that automatically controls the

speed

of a

motor vehicle.

The system is a

servomechanism

that

takes over the

throttle o

f the car to maintain a steady speed as set by the driver.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for wire harness connection between EMS and Cruise Cncl button.

4. Check for any back out of pins at EMS ECU connector.

5. Check for any damage of pins at EMS ECU connector.
