P0566-24: Brake booster pressure sensor circuit range / performance : Cruise Cncl button stuck key error

Overview:

DTC Description (User Friendly)

Brake booster pressure sensor circuit range / performance :

Cruise Cncl button stuck key error

ECU Pin Number

K029, K033

Customer Symptom

MIL OFF, CEL OFF

Fault Effects (On Vehicle)

Lamp Status (If Any)

Fault Detection Condition (Root cause)

Cruise Cncl button stuck key error is detected if CrC_stKey

continuously remains in a state of CRC_STCNCL for a

duration of 50 ms or 60000 ms.

Normal Operating Condition

Proper wire harness connection between Cruise Cncl button

and EMS ECU.

Probable Trouble Area

Wire harness connection between Cruise Cncl button and

EMS ECU.

Healing Condition

Rectify the error Clear through diagnostic tool.

Ignition OFF & ON

Component Details:

Cruise control is a system that automatically controls the

speed

of a

motor vehicle.

The system is a

servomechanism

that

takes over the

throttle o

f the car to maintain a steady speed as set by the driver.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Check for wire harness connection between EMS and Cruise Cncl button.

4. Check for any back out of pins at EMS ECU connector.

5. Check for any damage of pins at EMS ECU connector.

Trouble Shooting:

Step Checks

IF YES

IF NO
