C0040 – 11: Brake Pedal Switch - Circuit short to Ground
Overview:
ISO Code (DTC Code)
C0040 - 11
Customer Symptom
Brake lamps always OFF
Fault Effects (On Vehicle)
Brake lamps always OFF
Lamp Status (If Any)
Always OFF
Fault Detection Condition
This fault will be logged after the input switch test routine
execution. User has to operate the switch manually during
routine. If short to ground circuit fault is detected for Brake
Pedal selection switch then this DTC code will be returned
with the Routine results.
Normal Operating Condition
There should not be any fault returned by routine
Probable Trouble Area
1. BCM connector Fault
2. Cockpit harness Short to ground
3. Switch damaged or stuck
4. BCM ECU fault
5. Brake Pedal selection switch side connector fault.
Healing Condition
1. Ignition OFF
ON
2. Clear DTC Command
Component Details:
Brake Pedal Switch is operate manually. If the IGN is KeyIN/ Accessory/Keyout/ON/Run and user presses the
Brake, Brake lamps will be turned ON.
Preliminary Checks:
1. Check Battery Voltage (9V-16V)
2. Check ECU pins for oxidation, bending & damage.
Trouble Shooting:-
