B1C51-13
Left Rear Tweeter Assembly Output Power / Left Front Tweeter Assembly Input Signal -
circuit open
Overview:
Write up for the Related Sensor/Actuator or system:-
Rear left tweeter – This tweeter is located at the rear left door hand-side of rear passenger. It gives audible audio
as an output when any valid media source is played using infotainment system.
Pre-Check Points:
Perform tweeter tone test.
Trouble Shooting:-
Below given flowcharts guides to troubleshoot the fault:
ISO Code
B1C51-13
Customer Symptom
No audible audio output from rear left tweeter.
Fault Effects (On Vehicle)
No audible audio output from rear left tweeter.
Lamp Status (If Any)
No
Fault Detection Condition
3. No audible audio output from rear left tweeter .
4. This DTC gets logged when connection between rear
left tweeter and Silver Box is open.
Normal Operating Condition
When any media/radio source is played from infotainment
system, audio output is heard from car tweeter .
Probable Trouble Area
Wiring harness between Silver Box and tweeter
Silver box connector and connector terminals
Tweeter connector and its terminals
Intermittent connector and their terminals
Healing Condition
None
