Connector View & Information:-
Silver box Connector
Speaker Connector
Inspection Method (If any):-
NO
B1C09-13: Right Front Speaker Assembly Output Power / Right Front Speaker Assembly Input Signal
1 - circuit open
Overview:
ISO Code
B1C09-13
Customer Symptom
No audible audio output from front right speaker.
Fault Effects (On Vehicle)
No audible audio output from front right speaker.
Lamp Status (If Any)
No
Fault Detection Condition
1. No audible audio output from front right speaker.
2. This DTC gets logged when connection between
front right speaker and silver box is open.
Normal Operating Condition
When any media/radio source is played from infotainment
system, audio output is heard from car speakers.
Probable Trouble Area
Wiring harness between silver box and speakers
silver box connector and connector terminals
Speaker connector and its terminals
Intermittent connector and their terminals
Healing Condition
None
TBA
TBA
