Connector View & Information:-
Infotainment system Connector
Tweeter Connector
Inspection Method (If any):-
NO
B1C4E-13: Right Rear Tweeter Assembly Output Power / Right Rear Tweeter Assembly Input Signal
- circuit open
Overview:
Write up for the Related Sensor/Actuator or system:-
ISO Code
B1C4E-13
Customer Symptom
No audible audio output from rear right tweeter.
Fault Effects (On Vehicle)
No audible audio output from rear right tweeter.
Lamp Status (If Any)
No
Fault Detection Condition
3. No audible audio output from rear right tweeter.
4. This DTC gets logged when connection between rear
right tweeter and silver box is open.
Normal Operating Condition
When any media/radio source is played from infotainment
system, audio output is heard from car tweeter.
Probable Trouble Area
Wiring harness between silver box and tweeter
silverbox Connector and connector terminals
Tweeter connector and its terminals
Intermittent connector and their terminal
Healing Condition
None
TBA
TBA
