ELECTRICAL
129
ODOMETER
1. Odometer Indicates distance traveled by
vehicle within the range of 0 km to 999999 km
with the resolution of 1 km.
2. The Odometer reading freezes when reach to
maximum value.
TRIP METER A
1. Trip A Indicates distance traveled by vehicle
since last reset within the range of 0 km to
9999.9 km with the resolution of 0.1 km.
2. Trip A can be RESET to 0 by pressing Set
switch when display is in a TRIP A mode.
TRIP METER B
1. Trip B Indicates distance traveled by vehicle
since last reset within the range of 0 km to
9999.9 km with the resolution of 0.1 km.
2. Trip B can be RESET to 0 by pressing Set
switch when display is in a TRIP A mode.
DISTANCE TO EMPTY (DTE)
1. DTE indicates approximate distance (km) that
the vehicle can travel with available & usable
fuel in tank and the driving pattern.
2. This value may differ from the actual driving
distance.
3. ‘Refuel’ shall be displayed which indicates that
it’s the time to take your vehicle to the
nearest petrol pump to fill the fuel.
Note:
1. Take your vehicle to authorized TATA
MOTORS service station if DTE display’s ‘---‘
2. The DTE shall update with new value when
fuel is added more than approx. 6 Liters
3. The Average fuel consumption and Distance to
empty values may vary significantly based on
driving conditions, driving habits, and
condition of the vehicle and there is no
relation with the Odometer updation.
4. The distance to empty value is an estimate of
the available driving distance.
5. If low fuel warning comes, fill the fuel
immediately regardless the value of displayed
DTE.
6. If vehicle is not on level ground or negative of
battery has been disturbed, the DTE function
may not operate correctly
AVERAGE FUEL ECONOMY ‘A’
1. IPC shall display the “Average Fuel Economy
A” corresponding to ‘TRIP A’ with the
resolution of 0.1km/l.
2. Average Fuel Economy A shall reset to 0 when
Trip A is reset.
3. Average Fuel Economy A shall be displayed
as ‘--.-‘for initial 0.5 km of respective trip.
Once 0.5 km distance is covered, Average
Fuel Economy A shall be displayed.
AVERAGE FUEL ECONOMY ‘B’
4. IPC shall display the “Average Fuel Economy
B” corresponding to ‘TRIP B’ with the
resolution of 0.1km/l.
5. Average Fuel Economy B shall reset to 0 when
Trip B is reset.
6. Average Fuel Economy B shall be displayed
as ‘--.-‘for initial 0.5 km of respective trip.
Once 0.5 km distance is covered, Average
Fuel Economy B shall be displayed.
7. AFE shall vary frequently as per driving pattern
INSTANTANEOUS FUEL ECONOMY
1. Instantaneous Fuel Economy shows current or
instant fuel mileage of the vehicle when
ignition is turned ON and vehicle is on running
condition.
Note:
IFE shall vary frequently as per driving pattern.
User can change IFE units by using unit settings
only in export market
SETTINGS SCREEN
Following screen shall be seen in DIS by
pressing SET Switch in DTE / IFE Screen
