ELECTRICAL
126
TELL TALES
COLOR
INDICATOR
REMARKS
Malfunction
Indication Bulb
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF.
It remains ‘ON’ if there is malfunction in Engine system.
Engines performance deteriorates while it is running. Avoid
high speeds and Contact TATA MOTORS Authorized
Service Centre for rectification.
Check Engine
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if a fault arise in Engine
Management System. Contact TATA MOTORS Authorized
Service Centre.
Immobilizer
Red
(High End
– Amber)
1. Illuminates when the system disables engine start if the
original key is not used.
2. Bulb blinks: vehicle is in immobilized condition when key
is not inserted.
3. Bulb ON: Problem with key/system. Contact TATA
MOTORS Authorized Service Centre.
Water in fuel
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if excess water is accumulated in
the fuel filter. Contact TATA MOTORS Authorized Service
Centre to drain the water immediately to avoid serious
damage to the fuel injection system.
Speed Limit
bulb
Amber
This symbol comes ON when vehicle speed is more than
120 kmph. This symbol blinks and audible buzzer sounds
simultaneously when Vehicle Speed is more than 120
kmph. At this stage, reduce the vehicle speed.
Diesel
Particulate
Filter bulb
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after the engine starts. This symbol comes
ON when Diesel Particulate filter in exhaust system is
malfunctioning. At this stage, take the car to the nearest
Authorized Service outlet.
CNG Bulb
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when CNG fuel mode is activated.
Fuel Filter
Clogging Telltale
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should
go ‘OFF’ after 4 seconds. This symbol comes ON when Fuel
Filter Clogging warning is activated (if applicable)
CITY
Blue
This symbol lights up when the ‘IGN’ is turned ‘ON’ and should
go ‘OFF’ after 4 seconds. This symbol comes ON when CITY
driving mode is activated (if applicable).
