ELECTRICAL
125
TELL TALES
COLOR
INDICATOR
REMARKS
Airbag status
Red
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF.
It will continuously illuminate when there is malfunction of
airbag (SRS) system. Contact TATA MOTORS Authorized
Service Centre urgently.
EPAS
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF.
Illuminates when there is a fault in the EPAS. Contact
TATAMOTORS Authorized Service Centre urgently.
Co-Driver -
Seat belt
warning
Red
Seat belt warning indicator comes ‘ON’ for 4 seconds, when
ignition is turned ‘ON’ irrespective of seat belt buckle status.
If seat belt is not fastened then Telltale will be ON as initial
warning with No audio chime. If seat belt remains unbuckled
and vehicle speed goes above 15 kmph, Final Warning will
start with audio chime for 90 seconds continuously.
High Coolant
Temperature
Red
Indicates that engine coolant temperature is very high.
Illuminates when engine coolant temperature is very high
and continuously flashes along with buzzer if engine coolant
temperature is extremely high. Switch off the engine and
allow cooling. Top-up coolant if coolant level is low. Contact
TATA MOTORS Authorized Service Centre urgently.
Low Fuel
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF. Illuminates continuously if
fuel level is less than a pre-defined minimum level. Refill the
fuel tank as soon as possible. IMPORTANT: The warning
light flashes to indicate a fault in fuel system. Contact TATA
MOTORS Authorized Service Centre urgently.
NOTE: Driving with low fuel level condition can cause the
engine to misfire and damage the catalytic converter (if
equipped).
Door Open
White
Illuminates when doors are open or when they are not
completely closed. If the driver’s side door is not closed
properly, a beep will sound for a few secs. When the ignition
is ON.
ABS
Amber
Illuminates momentarily when ignition is switched ‘ON’ once
engine is cranked, it goes OFF. Illuminates continuously if
there is any malfunction in ABS. Normal braking system will
be operational without assistance of ABS. Contact TATA
MOTORS Authorized Service Centre urgently.
