1.5L REVOTORQ ENGINE
181
25.Connect the EVRVs hoses assembly to EGR
valve and turbocharger’s actuator.
ix. FITMENT OF INTAKE MANIFOLD
1. Loose fit the injector claws on the head cover.
2. Install all the four fuel injectors. Tighten the
injector claws.
3. Install the fuel rail assembly.
