433 / 1265
1.5L REVOTORQ ENGINE
178
7. Place the catcon gasket on the turbocharger.
Make sure to use new gasket when installing.
8. Align the catcon assembly with the
turbocharger outlet.
9. Install the turbocharger support brackets and
fix the catcon assembly to turbocharger.
10.Install the water housing elbow assembly.
11.Make the water housing elbow hoses
connection and fit the clamps at connection
ends.
12.Install the vacuum reservoir.
