386 / 1265
1.5L REVOTORQ ENGINE
131
J. COMPRESSOR MOTOR REMOVAL AND
REFITMENT
REMOVAL
1. Remove the compressor belt.
(For removal
procedures refer compressor and alternator
belt replacement).
2. Lift the vehicle on the two post lift.
3. Remove the suction and discharge hose of the
compressor.
4. Disconnect the electrical connection of the
compressor.
5. Loosen and remove the three mounting bolt
and take out the compressor.
6. Loosen and remove the mounting bolts and
take out the compressor support bracket.
REFITMENT
Follow the reverse order of removal procedure.
