1.5L REVOTORQ ENGINE
127
5. Lift the vehicle and remove the RH side front
mud liner.
(For procedure refer body section).
6. Remove the alternator and compressor belts.
(For procedure refer compressor and
alternator belt replacement).
7. Remove the top timing cover mounting bolts
accessible from below the vehicle.
8. Remove the mounting bolts and take out the
bottom timing cover.
9. Take the vehicle down and remove the top
timing cover from the top.
10.Relieve the tension by adjusting the auto
tensioner.
