1.5L REVOTORQ ENGINE
129
5. Loosen and remove the top mounting bolt of
the starter motor located on the transaxle
housing.
6. Lift the vehicle and remove the mounting
fasteners of the starter motor shield and take
out the shield.
7. Disconnect the electrical connection of the
starter motor.
8. Loosen and remove the bottom mounting
bolts of the starter motor.
9. Take out the starter motor along with harness
support brackets.
REFITMENT
Follow the reverse order of removal procedure.
