1.5L REVOTORQ ENGINE
124
F. TURBOCHARGER
REMOVAL
AND
REFITMENT
REMOVAL
1. Remove the clamps and disconnect the air
filter hoses.
2. Remove the air filter mounting bolts and pull
in outward direction to dislocate the filter
assembly from the locating bush on the rear
side. The air filter assembly will be come out
along with the dampener.
3. Remove the blow-by pipe using suitable
pliers.
4. Disconnect the electrical connection to mass
air flow sensor.
5. Remove the clamp and take out the pipe with
the air mass flow sensor connected to the
turbocharger.
