1.2L REVOTRON ENGINE
122
RADIATOR
REMOVAL
1. Drain the coolant and remove the Coolant
tank.
(For procedure refer “Coolant
replacement” in Engine maintenance section)
2. Disconnect the electrical connections to the
cooling fan shroud.
3. Disconnect the radiator top hose at radiator
end by removing spring band clamp.
4. Remove the inner mud liner of the front RH
wheel.
(For procedure refer Body section).
5. Remove the bracket and spring band clamp of
bottom hose at the thermostat end.
6. Discharge the refrigerant using standard
recovering equipment.
7. Loosen and remove the bolt and disconnect
the refrigerant inlet pipe.
