1.2L REVOTRON ENGINE
117
FUEL TANK
REMOVAL
1. Place the vehicle in a 2 poster lift.
2. Disconnect the electrical connections of the in-
tank pump and the fuel lines.
(For Removal
Refer Tank Unit removal process).
3. Disconnect the fuel filler hose and the breather
hose.
4. Support the fuel tank from below.
5. Remove the four mounting bolts from tank and
lower the tank carefully.
INSPECTION
Check all hoses and pipes connected to fuel
tank
for
leaks,
loose
connections,
deterioration or damage. Replace if
necessary.
Check fuel pump and fuel level gauge
gaskets for leaks, cracks etc. Replace if
necessary.
Visually inspect fuel tank for leaks and
damage. Replace if necessary.
Check TPV for dust accumulation. Clean if
required.
FITMENT
Follow the reverse order of removal for fitment.
