1.2L REVOTRON ENGINE
123
8. Loosen and remove the fastener and
disconnect the discharge pipe to condenser
.
CAUTION
Never leave the condenser lines open
immediately cover them with caps,
otherwise the desiccant which is in-built in
the condenser may absorb the moisture
from surrounding air and get contaminated
9. Remove front bumper and the splash guard.
(For procedure refer Body section).
10.Pry out the sealing rivets and remove both the
LH and RH front condenser sealing.
11.Remove the intercooler mounting bolts on the
condenser and unmount the intercooler.
