365 / 1133
1.5L REVOTORQ ENGINE
110
B. RADIATOR
REMOVAL
1. Drain the coolant and remove the coolant tank.
(For procedure refer "Coolant replacement" in
Engine Maintenance section)
2. Remove the front bumper.
(Refer front bumper
removal procedure from Body section).
3. Disconnect the electrical connections of the
cooling fan shroud.
4. Remove the spring clamp and disconnect the
hose connecting between thermostat and
radiator.
5. Remove the spring clamp and disconnect the
integral radiator hose.
6. Disconnect the overflow tube from radiator to
auxiliary tank.
7. Remove the intercooler.
(For procedure refer
intercooler removal process).
