1.5L REVOTORQ ENGINE
112
13.Remove the rear sealing on both LH and RH
side by prying out its locking rivets.
14.Remove the mounting rivets and take out the
top sealing assembly.
15.Remove the mounting rivets and take out the
bottom sealing assembly.
16.Remove the 4 mounting bolts and separate the
condenser assembly form the radiator.
