1.2L REVOTRON ENGINE
132
8. Remove the turbocharger oil intake and return
lines.
9. Remove the four mounting fasteners and take
out the turbocharger assembly along with the
inner side heat shield.
10. Remove the mounting bolts of the heat shield
and separate it from the turbo charger.
11. Remove Thermostat Cover by taking out the
3 bolts.
12. Remove the Thermostat from its housing.
