1.2L REVOTRON ENGINE
130
12. Removing the fasteners to take out the Intake
Manifold
II. Removal of Exhaust Manifold
1. Remove the Lambda sensor upper and lower
from CCC.
2. Remove the heat shield upper mounting bolts.
|
|
