1.2L REVOTRON ENGINE

127

H. REMOVAL OF ACCESSORIES

1. Rotate the tensioner point by using ring

spanner opposite to belt tension to loosen the

belt.

2. Remove the belt.

3. Remove the alternator mounting bolts and

take it out along with the bracket.

4. Remove the mounting bolts and take out the

compressor assembly.

5. Remove the mounting bolts and take out the

compressor mounting bracket.
