1.2L REVOTRON ENGINE

129

7. Loosen and remove the mounting bolt and

remove the temperature pressure sensor

mounted on the intake manifold.

8. Remove the Fuel Rail along with the injectors.

9. Remove the injector retainer on the fuel rail.

10.Remove the fuel injectors.

NOTE



Injector should be tagged as soon as it is

removed to avoid chances of it being

interchanged. Since the code of each

injector is calibrated to the EMS, whenever

an injector is replaced it codes of the

respective injectors should be fed in the

EMS ECU using diagnostic tool.

11. Loosen and remove the mounting bolts of the

bottom support bracket to the intake manifold.
