BODY
7
5. Operate the bonnet opening lever from inside
and ensure that the bonnet pops up properly, if
not loosen the mounting bolts and move the
lock in the oval slots provided in the mounting
holes, so that it opens properly.
6. Apply the recommended grease to the sliding
plates and cable.
HOOD LATCH STRIKER
REMOVAL
1. Open the bonnet.
2. Loosen and remove two mounting bolts and
remove the hood latch striker.
FITMENT
For fitment follow the reverse procedure of
removal.
BONNET LATCH RELEASE CABLE
REMOVAL
1. Open the bonnet.
2. Pull out the cable from the lock assembly.
3. Loosen and remove mounting fasteners of
hood release lever and remove the lever.
4. Remove locking pin as shown in figure.
