9. Insert plastic wedge pin and remove the door
trim.
NOTE
While lifting door trim, care should be taken such
that tree clips don’t get damage. Below image
gives the location of tree clips on door trim.
FITMENT
For fitment follow the reverse procedure of
removal.
9.2.11 DOOR INNER LOCK HANDLE
REMOVAL
1. Remove the door trim.
(For procedure refer
door trim removal process).
2. Remove inner handle screw cap.
3. Loosen and remove the mounting screw of
inner handle.
4. Remove one snap and two hooks located
behind the front door inner handle lever.
