3) If there is any fault in the system Low fuel warning symbol shall blink and fuel gauge shall not display the
BARS, take your car to the nearest Tata authorized service station to get it repaired.
2.3. Speedometer
At every key IN and Ignition ON, the speedometer needle moves to MAX and come back to ‘0’ position,
this indicates welcome strategy and self-check feature.
The Speedometer Indicates the actual vehicle speed in km/h.
Note
In Vehicle running condition if the Speedometer is not showing the Vehicle speed, take your vehicle to
TATA authorized service center
2.4. Temperature Gauge
The Temperature Gauge in the DIC indicates the Engine coolant temperature of the vehicle in the form of
a digital bar graph. This in conjunction with high engine coolant temperature telltale se rves as warn of the
coolant temperature state to the user.
Temperature gauge graphics color change from BLUE to “MIXED BLUE and RED’ color indicates Pre
temperature warning and change to all bars in RED color indicates engine coolant temperature value
reached to high temperature zone.
The Temperature Gauge indicates the temperature level of the engine coolant after Ignition ON.
High Coolant temp warning is given by turning on the telltale -
and Buzzer, along with all bars
turn to complete RED
High Coolant temperature warning may come when cooling fans in radiator sections are
malfunctioning.
CAUTION
RED color of temperature gauge along with telltale indicates high coolant temp warning. This indicates
overheating that may damage the engine. This may be due to insufficient coolant in the radiator or due to
any other defect. Take the car to the nearest authorized Tata service station.
